HP-N-150
$622.00

COXREELS® SH Series Super Hub™ Spring Driven Hose Reels, like the P Series, have a long history of dependable performance. The larger chassis and frame accommodate longer lengths and larger diameters of hose. COXREELS® original Super Hub™ dual axle support system increases the stability during operation, reduces vibration and strengthens the structural integrity of the reel.

Features

  • Swivel - machined from zinc plated steel 90 deg full flow NPT swivel for simple seal maintenance and fast and easy hose installation
  • No need to remove the reel from its mount
  • Cartridge motor - lubricated and enclosed cartridge style motor is easily removable for safe and convenient maintenance
  • CNC spun disc - heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety
  • 1/4 in steel base - sturdy single pedestal design with solid one-piece steel base and support post, no weld, for maximum stability and professional grade strength without the weight
  • Equipped with COXREELS® exclusive Super Hub™ dual axle support
  • Multi-position guide arm - versatile multi-position guide arm adjusts to wall, floor, ceiling and vehicle mounting positions
  • Long-lasting, chip-resistant and rust inhibiting CPC™ powder coat finish, adjustable solid rubber hose stop and sturdy permanently lubricated precision bearing

Specifications

Finish CPC™ Powder Coated
Series SH Series
Material Steel
Type 1-Pedestal Heavy Duty High Pressure
Color Blue
Dimensions 19-1/2 in L x 8-3/4 in W x 25-1/2 in H
Domestic/Import Import
Drive Type Cartridge Style Spring Motor
Hose Capacity 1/4 in ID x 9/16 in OD x 50 ft L
Mounting Type Bench/Ceiling/Floor/Vehicle

Application

Air/Water Services, Pneumatic Tools, Washdown, Lubrication, Chemical Fluid Transfer, General Industrial, Manufacturing Plants and Facilities, Maintenance, Repair and Operations, Automotive and Fleet Service Centers, Grease and Hydraulic Oil Applications
